2026 Merida eBIG Nine 300 SE

You don't need to spend a fortune to enjoy the world of e-biking. The budget-focused eBIG.NINE 300 SE models deliver a quality ride thanks to an aluminium frame and powerful but refined Shimano EP5 drive unit, but with the convenience of an easily removable externally mounted 504 Wh battery. Powerful, all-weather Shimano hydraulic disc brakes are on hand to keep control and the tough, durable 8sp ESSA drivetrain offers plenty of gearing for off-road adventures or the city streets.

Arguably the most versatile e-bike in Merida's range, the tried and tested eBIG.NINE embodies the perfect balance of day-to-day usability and sporty leisure activity. It's a bike that can handle serious off-road riding but can also handle the commute to work with ease - especially if you want to have some fun on the way. The high-quality aluminium frame integrates an economical frame featuring semi-integrated 504 Wh battery. All feature powerful and smooth Shimano drive units that will power you up any hill. Ready to be equipped with mudguards and even a side stand, the eBIG.NINE will help you make the most of any situation.

Features:

Powerful Shimano EP5 motor, 60Nm torque
Long-lasting 504Wh Shimano battery
Durable alloy frame, crossbar style
Suntour XCM34-Boost fork, 100mm travel
Shimano MT-200 hydraulic disc brakes

SPECIFICATIONS
FRAME    eBIG.NINE LITE
SHOCK
FORK    Suntour XCM34-Boost LOR DS, 100mm, Tapered, 51mm fork offset, 29x2.4" max WHS,
BRAKE FRONT    Shimano MT-200, 2 piston
BRAKE REAR    Shimano MT-200, 2 piston
ROTOR FRONT    Shimano RT10, 180 mm
ROTOR REAR    Shimano RT10, 180 mm
CHAIN    KMC Z8.3 EPT
CRANKSET    Prowheel EB11, 165mm for all sizes
CRANK LENGTH    Prowheel Pro38P-S16-49, 38t
DERAILLEUR REAR    Shimano Essa
CASSETTE    Shimano HG300, 11-45 8sp
PEDAL    VP VPE-891
GRIP    MERIDA COMP TK
HANDLEBAR    MERIDA EXPERT, MAT aluminium, 680 WHB, 15 RHB
STEM    MERIDA COMP CC, MAT aluminium, 31.8 DSH, 7 ASD
STEM SIZE    90 mm all sizes
HEADSET    MERIDA-2341 (for the steerer 1-1/8"~1.5")
HUB FRONT    Shimano QC300, 100x9 WHF, 32 SPH, Centerlock
HUB REAR    Shimano TC500-HM-B, 148x12 WHR, 36 SPH, Centerlock
RIM    MERIDA COMP TK, 20 IWR, MAT aluminium
SADDLE    MERIDA Expert TK, 168 width
SEAT CLAMP    MERIDA EXPERT,
SEAT POST    MERIDA COMP CC, MAT aluminium, 30.9 DSP, 0 SSB
SHIFTER FRONT
SHIFTER REAR    Shimano ALTUS
TYRE FRONT    Kenda Booster, 29x2.2", wire
TYRE REAR    Kenda Booster, 29x2.2", wire
LIGHT FRONT    CG-119PG
LIGHT REAR    CG-404RG
DRIVE UNIT    Shimano EP5, 60Nm
BATTERY    Shimano EN604 Battery, 504Wh
DISPLAY    Shimano SC-EN500
KICKSTAND    Uses 18mm kickstand
